TBXE-T001
Use of the display control box included in this set re-enables the display function of the air-conditioner information in aftermarket A/V equipment.

TBXE-T001 Installation example
  • 1.Panel
  • 2.Blacket(L)(R)
  • 3.Bracket(1set)
  • 4.24P connector
  • 5.Display control box
  • 6.Speed pulse signal cord
  • Etc.
Designed Installation Size
Double DIN or 1 DIN + 1 DIN
Compatibility
Model No. of Speakers Model Year
MAZDA 3 4-Door 5-Door 4
6
Oct.2003 - Nov.2005
MAZDA 3 4-Door 5-Door 4
6
7
Oct.2003 - Nov.2005

Car models with the BOSE sound system use a separate amplifier. Optional sound system translator for MAZDA Models TBXE-X001 is required for proper operation.
As cars with remote audio control switches on the steering wheel are disabled, installation of optional parts FPCE-T001 enables the operation of an audio remote control switch on the steering wheel.
By using an optional UAE-Y201DV, an on-dash monitor can be mounted without disturbing the frontal view.
This model is compatible with the Factory DVD car navigation system although the TV function is disabled.However, the TV function on the aftermarket car navigation system can operate.
The information-center-display including the clock and audio become disabled.
Dimming function that works when either head lights or parking lights are on is disabled.
This set is compatible with models with a manual-control air conditioner (Oct 2003 to Oct 2004). However,the information-center-display only shows the AMB (ambient temperature), same as the Factory equipment.
On car models with manual air conditioning controls produced after October 2004, an error "---" is displayed since no AMB (ambient temperature) display function is in the Factory equipment. Instead, this set's original messages are displayed on the information-center-display (See display above).
For models without the Factory navigation system, there is no speed pulse signal from the vehicle side. For installation of a car navigation system, it is necessary to connect the speed pulse signal cord included in this set.
